| 日期 (UTC) | 20240101 |
|---|---|
| 事件總數 | 191 |
| ↑ up (紅) | 17 |
| ↓ down (橘) | 114 |
| 共模噪音 (綠) | 59 |
| noise_large (洋紅) | 1 |
| CWA 地震 (紫★) | 0 |
| RMS max | 0.000 |
| RMS median | 0.000 |
| RMS mean | 0.000 |
互動版（24 條小時線）：點圖例中的小時色塊 → 該小時線變明顯、其餘變半透明；再點一次還原。
點擊上圖的紅色 up 事件以顯示 waterfall plot。
MiDAS Daily RMS peaks — 20240101 Total: 191 events [RMS_below300m 欄位說明] 來源 : 2024 backfill nc（100Hz decimated，Hole A trace 1307–1403，跳過頂部 73 ch，對應深度 ~300–700 m） 前處理: per-file bad-channel masking(median+10×MAD) → bandpass 1–20 Hz（sosfiltfilt，逐檔獨立，非跨檔 causal filter state） 公式 : sqrt( sum(x[ch,t]^2) / (97 ch × 100 samples) ) / DAS_SENSITIVITY 意義 : STA/LTA 偵測峰值那一秒，97 個 channel × 100 個取樣點的 RMS 振幅 單位 : strain rate (1/s)，已轉換為物理應變率（DAS_SENSITIVITY=7.0621e+08） 參考值: 典型背景 ~7.08e-10–2.83e-09，大地震 > 1.13e-08 RMS stats mean=4.327e-09 std=4.021e-09 min=2.312e-09 Q25=2.919e-09 median=3.312e-09 Q75=3.828e-09 max=3.150e-08 ID timestamp_tw (UTC+8) RMS_below300m fk_label CWA ------------------------------------------------------------------ 000 2024-01-01 08:01:30 4.473e-09 down 0 001 2024-01-01 08:03:16 3.718e-09 down 0 002 2024-01-01 08:08:56 3.004e-09 down 0 003 2024-01-01 08:09:15 9.921e-09 up 0 004 2024-01-01 08:09:36 3.148e-09 noise 0 005 2024-01-01 08:09:48 1.208e-08 up 0 006 2024-01-01 08:10:25 3.028e-08 up 0 007 2024-01-01 08:10:44 4.531e-09 up 0 008 2024-01-01 08:11:14 1.811e-08 down 0 009 2024-01-01 08:12:53 3.476e-09 down 0 010 2024-01-01 08:13:14 3.179e-09 down 0 011 2024-01-01 08:15:25 3.684e-09 noise 0 012 2024-01-01 08:18:45 3.728e-09 noise 0 013 2024-01-01 08:19:24 3.509e-09 noise 0 014 2024-01-01 08:20:00 3.056e-09 noise 0 015 2024-01-01 08:22:35 3.652e-09 down 0 016 2024-01-01 08:25:58 3.896e-09 noise 0 017 2024-01-01 08:29:20 2.897e-09 noise 0 018 2024-01-01 08:30:07 3.338e-09 down 0 019 2024-01-01 08:30:25 2.872e-09 down 0 020 2024-01-01 08:31:08 3.067e-09 noise 0 021 2024-01-01 08:37:12 2.671e-09 down 0 022 2024-01-01 08:37:51 3.135e-09 down 0 023 2024-01-01 08:39:08 3.418e-09 down 0 024 2024-01-01 08:41:36 3.900e-09 down 0 025 2024-01-01 08:43:59 3.133e-09 noise 0 026 2024-01-01 08:45:06 3.262e-09 noise 0 027 2024-01-01 08:46:17 2.858e-09 down 0 028 2024-01-01 08:47:13 4.348e-09 down 0 029 2024-01-01 08:50:54 3.311e-09 down 0 030 2024-01-01 08:51:39 2.803e-09 down 0 031 2024-01-01 08:54:48 3.183e-09 down 0 032 2024-01-01 08:57:01 2.932e-09 down 0 033 2024-01-01 08:58:16 3.330e-09 noise 0 034 2024-01-01 09:10:05 3.382e-09 down 0 035 2024-01-01 09:12:34 3.608e-09 noise 0 036 2024-01-01 09:13:49 3.825e-09 down 0 037 2024-01-01 09:17:35 3.175e-09 noise 0 038 2024-01-01 09:19:18 3.241e-09 noise 0 039 2024-01-01 09:20:36 4.184e-09 down 0 040 2024-01-01 09:21:26 3.209e-09 noise 0 041 2024-01-01 09:26:06 4.331e-09 down 0 042 2024-01-01 09:26:55 4.270e-09 noise 0 043 2024-01-01 09:27:14 5.079e-09 down 0 044 2024-01-01 09:29:50 3.990e-09 down 0 045 2024-01-01 09:32:39 3.190e-09 noise 0 046 2024-01-01 09:34:50 2.965e-09 down 0 047 2024-01-01 09:37:14 2.926e-09 noise 0 048 2024-01-01 09:43:17 3.390e-09 down 0 049 2024-01-01 09:45:02 3.695e-09 noise 0 050 2024-01-01 09:47:24 3.596e-09 down 0 051 2024-01-01 09:47:40 3.858e-09 noise 0 052 2024-01-01 10:03:36 3.341e-09 noise 0 053 2024-01-01 10:05:06 3.373e-09 noise 0 054 2024-01-01 10:05:42 3.687e-09 noise 0 055 2024-01-01 10:08:16 4.014e-09 noise 0 056 2024-01-01 10:08:40 3.191e-09 noise 0 057 2024-01-01 10:10:50 3.431e-09 down 0 058 2024-01-01 10:13:55 3.196e-09 down 0 059 2024-01-01 10:14:12 3.094e-09 noise 0 060 2024-01-01 10:25:22 3.289e-09 noise 0 061 2024-01-01 10:27:27 2.908e-09 down 0 062 2024-01-01 10:28:45 2.861e-09 down 0 063 2024-01-01 10:31:00 3.237e-09 down 0 064 2024-01-01 10:34:33 3.686e-09 noise 0 065 2024-01-01 10:34:48 3.483e-09 down 0 066 2024-01-01 11:00:10 2.550e-09 down 0 067 2024-01-01 11:02:52 2.859e-09 down 0 068 2024-01-01 11:14:03 3.186e-09 down 0 069 2024-01-01 11:21:09 3.663e-09 down 0 070 2024-01-01 11:25:27 2.760e-08 down 0 071 2024-01-01 11:25:48 1.959e-08 down 0 072 2024-01-01 11:26:04 1.004e-08 up 0 073 2024-01-01 11:34:12 2.710e-09 down 0 074 2024-01-01 11:42:25 3.206e-09 down 0 075 2024-01-01 11:55:02 2.912e-09 noise 0 076 2024-01-01 11:59:31 5.328e-09 noise 0 077 2024-01-01 12:13:52 2.851e-09 down 0 078 2024-01-01 12:20:07 2.445e-09 noise 0 079 2024-01-01 12:30:54 9.410e-09 up 0 080 2024-01-01 12:33:45 5.130e-09 up 0 081 2024-01-01 12:35:23 3.029e-09 down 0 082 2024-01-01 12:37:28 2.869e-09 down 0 083 2024-01-01 12:43:46 3.123e-09 down 0 084 2024-01-01 12:48:41 2.512e-09 down 0 085 2024-01-01 12:56:33 3.803e-09 down 0 086 2024-01-01 13:09:02 2.823e-09 down 0 087 2024-01-01 13:20:04 3.523e-09 down 0 088 2024-01-01 13:26:18 3.731e-09 down 0 089 2024-01-01 13:28:06 3.220e-09 down 0 090 2024-01-01 13:47:57 3.930e-09 down 0 091 2024-01-01 13:55:56 2.722e-09 down 0 092 2024-01-01 14:00:22 2.937e-09 noise 0 093 2024-01-01 14:01:55 3.273e-09 down 0 094 2024-01-01 14:02:56 4.203e-09 up 0 095 2024-01-01 14:08:01 2.768e-09 down 0 096 2024-01-01 14:16:09 2.492e-09 down 0 097 2024-01-01 14:16:27 2.933e-09 noise 0 098 2024-01-01 15:04:40 2.640e-09 down 0 099 2024-01-01 15:15:03 4.256e-09 noise 0 100 2024-01-01 15:15:21 3.793e-09 noise 0 101 2024-01-01 15:15:37 4.555e-09 noise 0 102 2024-01-01 15:44:07 3.596e-09 down 0 103 2024-01-01 16:03:42 2.952e-09 down 0 104 2024-01-01 16:30:55 3.843e-09 noise 0 105 2024-01-01 16:54:51 2.665e-09 noise 0 106 2024-01-01 17:07:56 2.643e-09 down 0 107 2024-01-01 17:15:47 2.769e-09 noise 0 108 2024-01-01 17:25:25 2.451e-09 noise 0 109 2024-01-01 17:32:42 2.929e-09 down 0 110 2024-01-01 17:34:01 3.042e-09 up 0 111 2024-01-01 17:45:17 3.078e-09 down 0 112 2024-01-01 17:59:10 3.059e-09 down 0 113 2024-01-01 18:05:53 3.055e-09 down 0 114 2024-01-01 18:14:05 3.978e-09 noise 0 115 2024-01-01 18:19:04 2.880e-09 down 0 116 2024-01-01 18:20:11 2.754e-09 down 0 117 2024-01-01 18:20:33 3.234e-09 down 0 118 2024-01-01 18:28:15 3.826e-09 down 0 119 2024-01-01 18:35:50 3.070e-09 noise 0 120 2024-01-01 18:55:33 4.397e-09 down 0 121 2024-01-01 18:57:52 2.899e-09 down 0 122 2024-01-01 19:02:22 2.685e-09 down 0 123 2024-01-01 19:13:14 3.021e-09 down 0 124 2024-01-01 19:15:12 2.887e-09 down 0 125 2024-01-01 19:15:40 3.706e-09 noise 0 126 2024-01-01 19:23:18 2.394e-09 down 0 127 2024-01-01 19:30:47 3.362e-09 down 0 128 2024-01-01 19:31:03 4.859e-09 up 0 129 2024-01-01 19:37:22 3.500e-09 down 0 130 2024-01-01 19:38:38 3.830e-09 down 0 131 2024-01-01 19:47:14 2.763e-09 down 0 132 2024-01-01 19:49:19 2.499e-09 down 0 133 2024-01-01 19:50:56 3.620e-09 down 0 134 2024-01-01 19:52:11 2.617e-09 down 0 135 2024-01-01 19:52:48 6.266e-09 down 0 136 2024-01-01 19:54:07 2.843e-09 down 0 137 2024-01-01 19:55:15 2.784e-09 down 0 138 2024-01-01 19:55:41 3.197e-09 down 0 139 2024-01-01 20:00:15 3.390e-09 down 0 140 2024-01-01 20:02:10 3.371e-09 down 0 141 2024-01-01 20:10:36 2.699e-09 down 0 142 2024-01-01 20:12:03 3.523e-09 down 0 143 2024-01-01 20:13:52 5.170e-09 down 0 144 2024-01-01 20:14:27 2.584e-09 noise 0 145 2024-01-01 20:31:26 3.704e-09 down 0 146 2024-01-01 20:33:07 4.219e-09 down 0 147 2024-01-01 20:37:11 3.691e-09 down 0 148 2024-01-01 20:37:47 3.263e-09 down 0 149 2024-01-01 20:46:13 3.459e-09 down 0 150 2024-01-01 20:47:48 2.487e-09 down 0 151 2024-01-01 20:52:56 2.931e-09 noise 0 152 2024-01-01 21:11:47 2.572e-09 down 0 153 2024-01-01 21:14:12 3.203e-09 down 0 154 2024-01-01 21:20:35 2.984e-09 down 0 155 2024-01-01 21:21:52 2.348e-09 down 0 156 2024-01-01 21:39:18 3.452e-09 noise 0 157 2024-01-01 21:51:28 3.330e-09 up 0 158 2024-01-01 21:56:30 3.050e-09 down 0 159 2024-01-01 21:59:05 3.478e-09 noise 0 160 2024-01-01 22:17:38 3.741e-09 down 0 161 2024-01-01 23:01:30 2.312e-09 noise 0 162 2024-01-01 23:03:52 2.866e-09 down 0 163 2024-01-02 00:25:32 4.391e-09 up 0 164 2024-01-02 00:41:42 9.772e-09 noise 0 165 2024-01-02 01:43:21 3.443e-09 down 0 166 2024-01-02 01:47:12 3.315e-09 down 0 167 2024-01-02 02:44:04 8.579e-09 up 0 168 2024-01-02 02:44:16 9.908e-09 up 0 169 2024-01-02 02:51:11 3.036e-09 down 0 170 2024-01-02 02:52:48 3.312e-09 up 0 171 2024-01-02 02:58:58 4.465e-09 down 0 172 2024-01-02 02:59:44 3.150e-08 down 0 173 2024-01-02 03:08:15 2.864e-09 down 0 174 2024-01-02 03:28:04 4.076e-09 up 0 175 2024-01-02 03:37:10 2.379e-09 noise 0 176 2024-01-02 04:15:44 3.400e-09 down 0 177 2024-01-02 04:24:33 3.888e-09 down 0 178 2024-01-02 04:33:14 1.756e-08 noise_large 0 179 2024-01-02 05:09:13 3.365e-09 noise 0 180 2024-01-02 05:12:28 4.450e-09 noise 0 181 2024-01-02 05:20:14 8.647e-09 noise 0 182 2024-01-02 05:45:59 2.839e-09 down 0 183 2024-01-02 06:00:51 2.716e-09 down 0 184 2024-01-02 06:08:27 3.732e-09 noise 0 185 2024-01-02 06:09:09 2.793e-09 noise 0 186 2024-01-02 06:11:30 1.128e-08 noise 0 187 2024-01-02 06:14:45 5.990e-09 up 0 188 2024-01-02 06:54:21 3.156e-09 noise 0 189 2024-01-02 07:01:39 3.866e-09 noise 0 190 2024-01-02 07:53:40 2.739e-09 noise 0
