| 日期 (UTC) | 20240513 |
|---|---|
| 事件總數 | 146 |
| ↑ up (紅) | 107 |
| ↓ down (橘) | 27 |
| 共模噪音 (綠) | 12 |
| noise_large (洋紅) | 0 |
| CWA 地震 (紫★) | 0 |
| RMS max | 0.000 |
| RMS median | 0.000 |
| RMS mean | 0.000 |
互動版（24 條小時線）：點圖例中的小時色塊 → 該小時線變明顯、其餘變半透明；再點一次還原。
點擊上圖的紅色 up 事件以顯示 waterfall plot。
MiDAS Daily RMS peaks — 20240513 Total: 146 events [RMS_below300m 欄位說明] 來源 : 2024 backfill nc（100Hz decimated，Hole A trace 1307–1403，跳過頂部 73 ch，對應深度 ~300–700 m） 前處理: per-file bad-channel masking(median+10×MAD) → bandpass 1–20 Hz（sosfiltfilt，逐檔獨立，非跨檔 causal filter state） 公式 : sqrt( sum(x[ch,t]^2) / (97 ch × 100 samples) ) / DAS_SENSITIVITY 意義 : STA/LTA 偵測峰值那一秒，97 個 channel × 100 個取樣點的 RMS 振幅 單位 : strain rate (1/s)，已轉換為物理應變率（DAS_SENSITIVITY=7.0621e+08） 參考值: 典型背景 ~7.08e-10–2.83e-09，大地震 > 1.13e-08 RMS stats mean=1.447e-08 std=3.178e-08 min=2.622e-09 Q25=3.992e-09 median=5.589e-09 Q75=9.793e-09 max=2.469e-07 ID timestamp_tw (UTC+8) RMS_below300m fk_label CWA ------------------------------------------------------------------ 000 2024-05-13 08:01:48 4.457e-09 up 0 001 2024-05-13 08:04:55 2.954e-09 up 0 002 2024-05-13 08:09:11 3.519e-09 down 0 003 2024-05-13 08:35:41 4.478e-09 down 0 004 2024-05-13 08:45:19 4.947e-08 up 0 005 2024-05-13 08:48:26 4.580e-09 up 0 006 2024-05-13 08:53:44 3.882e-09 down 0 007 2024-05-13 09:28:10 3.874e-09 down 0 008 2024-05-13 09:32:44 4.499e-09 up 0 009 2024-05-13 09:35:10 6.029e-09 down 0 010 2024-05-13 09:44:10 4.581e-09 down 0 011 2024-05-13 09:54:21 1.347e-08 up 0 012 2024-05-13 10:00:16 3.898e-09 noise 0 013 2024-05-13 10:01:46 7.015e-09 up 0 014 2024-05-13 10:02:03 5.102e-09 up 0 015 2024-05-13 10:13:03 4.004e-09 noise 0 016 2024-05-13 10:19:22 4.141e-09 up 0 017 2024-05-13 10:45:27 7.063e-09 up 0 018 2024-05-13 10:49:45 4.353e-09 up 0 019 2024-05-13 10:58:03 4.248e-09 up 0 020 2024-05-13 10:59:05 5.065e-09 up 0 021 2024-05-13 11:02:37 4.739e-09 up 0 022 2024-05-13 11:03:15 5.587e-09 up 0 023 2024-05-13 11:03:29 1.887e-08 up 0 024 2024-05-13 11:06:43 8.508e-09 up 0 025 2024-05-13 11:09:33 2.316e-08 up 0 026 2024-05-13 11:15:35 7.612e-09 up 0 027 2024-05-13 11:17:57 1.269e-08 up 0 028 2024-05-13 11:29:08 5.070e-09 down 0 029 2024-05-13 11:31:07 3.281e-08 up 0 030 2024-05-13 11:43:54 5.779e-09 up 0 031 2024-05-13 11:48:11 7.610e-09 up 0 032 2024-05-13 12:21:49 4.082e-09 up 0 033 2024-05-13 12:31:22 1.342e-08 up 0 034 2024-05-13 12:56:05 8.515e-09 up 0 035 2024-05-13 13:01:06 5.886e-09 up 0 036 2024-05-13 13:35:20 3.241e-09 up 0 037 2024-05-13 13:35:52 3.782e-09 down 0 038 2024-05-13 13:37:50 1.729e-08 up 0 039 2024-05-13 13:41:07 1.100e-08 up 0 040 2024-05-13 13:57:15 1.263e-08 up 0 041 2024-05-13 14:06:00 4.513e-09 up 0 042 2024-05-13 14:06:21 3.962e-08 up 0 043 2024-05-13 14:15:02 2.124e-08 up 0 044 2024-05-13 14:15:47 1.018e-08 up 0 045 2024-05-13 14:17:20 6.906e-09 up 0 046 2024-05-13 14:20:15 6.924e-08 up 0 047 2024-05-13 14:24:07 1.199e-08 up 0 048 2024-05-13 14:30:36 3.885e-09 down 0 049 2024-05-13 14:34:14 3.898e-09 noise 0 050 2024-05-13 14:41:34 7.256e-09 up 0 051 2024-05-13 14:52:09 4.644e-09 up 0 052 2024-05-13 14:56:43 1.396e-08 up 0 053 2024-05-13 15:08:01 5.078e-09 up 0 054 2024-05-13 15:19:50 4.393e-09 down 0 055 2024-05-13 15:29:03 7.880e-09 up 0 056 2024-05-13 15:37:36 6.673e-09 up 0 057 2024-05-13 15:42:03 5.978e-09 up 0 058 2024-05-13 15:42:51 4.880e-09 down 0 059 2024-05-13 15:57:54 9.140e-08 up 0 060 2024-05-13 16:08:04 3.550e-09 down 0 061 2024-05-13 16:14:42 4.826e-09 up 0 062 2024-05-13 16:16:51 4.782e-09 up 0 063 2024-05-13 16:27:39 5.623e-09 up 0 064 2024-05-13 16:33:09 2.470e-08 up 0 065 2024-05-13 16:47:20 8.938e-09 up 0 066 2024-05-13 17:05:20 5.506e-09 down 0 067 2024-05-13 17:10:58 4.101e-09 noise 0 068 2024-05-13 17:11:30 3.459e-09 down 0 069 2024-05-13 17:19:57 7.673e-09 up 0 070 2024-05-13 17:29:59 3.456e-09 down 0 071 2024-05-13 17:32:23 3.353e-09 down 0 072 2024-05-13 17:50:21 3.485e-09 down 0 073 2024-05-13 17:54:19 4.348e-09 noise 0 074 2024-05-13 17:58:02 3.988e-09 noise 0 075 2024-05-13 18:14:56 3.299e-09 down 0 076 2024-05-13 18:15:34 9.765e-09 up 0 077 2024-05-13 18:30:57 2.971e-09 noise 0 078 2024-05-13 18:41:45 1.848e-08 up 0 079 2024-05-13 18:42:55 9.863e-08 up 0 080 2024-05-13 18:58:46 4.006e-09 up 0 081 2024-05-13 19:01:58 9.012e-09 up 0 082 2024-05-13 19:27:09 3.407e-09 up 0 083 2024-05-13 19:30:54 3.962e-09 noise 0 084 2024-05-13 19:44:52 8.715e-09 down 0 085 2024-05-13 20:09:51 3.235e-08 up 0 086 2024-05-13 20:11:12 3.120e-09 noise 0 087 2024-05-13 20:14:54 3.223e-09 noise 0 088 2024-05-13 20:47:17 3.265e-09 down 0 089 2024-05-13 20:57:54 4.858e-09 down 0 090 2024-05-13 20:59:47 4.632e-09 down 0 091 2024-05-13 21:20:35 5.341e-09 up 0 092 2024-05-13 21:27:55 5.818e-09 up 0 093 2024-05-13 21:58:29 9.802e-09 up 0 094 2024-05-13 21:59:43 6.223e-09 up 0 095 2024-05-13 22:02:01 2.869e-09 noise 0 096 2024-05-13 22:10:18 8.819e-09 up 0 097 2024-05-13 22:11:08 2.049e-07 up 0 098 2024-05-13 22:18:02 5.592e-09 up 0 099 2024-05-13 22:26:22 3.918e-09 up 0 100 2024-05-13 23:15:34 2.977e-09 noise 0 101 2024-05-13 23:38:06 3.965e-09 up 0 102 2024-05-13 23:48:22 6.734e-09 up 0 103 2024-05-13 23:55:55 2.469e-07 up 0 104 2024-05-14 00:00:04 3.213e-09 up 0 105 2024-05-14 00:01:26 5.935e-09 up 0 106 2024-05-14 00:16:14 7.149e-09 up 0 107 2024-05-14 00:32:23 7.720e-09 up 0 108 2024-05-14 00:48:55 1.238e-08 up 0 109 2024-05-14 01:13:28 4.111e-09 up 0 110 2024-05-14 01:25:55 3.094e-09 down 0 111 2024-05-14 02:01:44 6.483e-09 down 0 112 2024-05-14 02:02:20 7.637e-09 up 0 113 2024-05-14 02:07:01 7.309e-09 up 0 114 2024-05-14 02:15:10 3.353e-09 up 0 115 2024-05-14 02:25:25 2.576e-08 up 0 116 2024-05-14 02:27:01 4.845e-09 up 0 117 2024-05-14 02:39:12 3.529e-09 up 0 118 2024-05-14 02:44:25 9.887e-09 up 0 119 2024-05-14 02:46:39 9.856e-09 up 0 120 2024-05-14 02:58:02 4.301e-09 up 0 121 2024-05-14 03:22:13 3.393e-09 up 0 122 2024-05-14 04:08:05 2.622e-09 down 0 123 2024-05-14 04:20:58 3.526e-09 up 0 124 2024-05-14 04:24:07 7.563e-09 up 0 125 2024-05-14 04:35:08 7.091e-09 up 0 126 2024-05-14 04:37:10 5.800e-09 up 0 127 2024-05-14 04:38:57 5.246e-09 up 0 128 2024-05-14 04:40:51 4.897e-08 up 0 129 2024-05-14 04:45:11 3.184e-09 up 0 130 2024-05-14 04:53:21 1.342e-08 up 0 131 2024-05-14 05:17:34 2.030e-08 down 0 132 2024-05-14 05:24:20 3.480e-09 up 0 133 2024-05-14 05:27:08 4.368e-09 up 0 134 2024-05-14 05:37:32 1.481e-07 up 0 135 2024-05-14 05:39:20 8.344e-09 up 0 136 2024-05-14 05:47:57 1.298e-08 up 0 137 2024-05-14 06:08:09 3.463e-09 up 0 138 2024-05-14 06:30:39 7.041e-09 up 0 139 2024-05-14 06:33:59 2.920e-09 up 0 140 2024-05-14 07:14:34 4.313e-09 up 0 141 2024-05-14 07:17:01 1.097e-08 up 0 142 2024-05-14 07:23:26 2.125e-08 down 0 143 2024-05-14 07:25:44 4.728e-09 up 0 144 2024-05-14 07:28:51 1.682e-08 up 0 145 2024-05-14 07:58:29 1.098e-07 up 0
